HV-2
HAIVOL
8535100000
Our 11kV High Voltage Electrical Distribution Standard Fuse Cutout (Model: HV-2) is an industry-leading drop-out fuse cutout engineered for reliable short-circuit protection and switching operations in 10kV to 38kV electrical distribution systems. As a core protective device compliant with global standards, this standard fuse cutout is widely deployed on the primary side of distribution transformers, distribution network branch lines, and capacitor banks, delivering economical, easy-to-operate, and highly adaptable protection solutions for power distribution infrastructure. Manufactured under strict quality controls, our electrical distribution fuse cutout fully aligns with the latest IEC and IEEE standards, making it the preferred choice for power utility providers, electrical engineering contractors, and industrial facility operators seeking stable, standardized distribution protection.
Rated voltage(KV) | Rated current(A) | Rated interrupting current(KA) | Lightning impulse withstand voltage to ground (BIL KV) | Minimum power frequency withstand dry voltage to ground (KV) | Minimum creepage distance(mm) |
11-15 | 100/200 | 12 | 110 | 42 | 220 |
11-15 | 100/200 | 12 | 125 | 50 | 320 |
24-27 | 100/200 | 12 | 150 | 65 | 470 |
33-38 | 100/200 | 8 | 170 | 70 | 660 |
33-38 | 100/200 | 8 | 170 | 70 | 720 |
33-38 | 100/200 | 8 | 170 | 70 | 900 |
 |  |  |
 |  |  |
This high voltage fuse cutout features industry-leading weather resistance for long-term outdoor operation. Porcelain insulators use US-made CGM INC por-rok anchoring cement for cement pouring, delivering rapid solidification, high mechanical strength, and low expansion coefficient. Polymer insulators adopt one-piece injection molding with high-temperature vulcanized silicone rubber, ensuring excellent sealing and tracking erosion resistance. All ferrous parts undergo hot-dip galvanizing with a zinc coating over 86μm for superior corrosion resistance.
Our electrical distribution standard fuse cutout adopts a single vent design, with downward and outward exhaust during interruption to prevent rainwater intrusion and improve interrupting capacity. All copper castings use high-grade bronze/brass, with silver-plated convex contact surfaces to reduce contact resistance and ensure excellent conductivity. High-strength memory copper alloy sheets guarantee stable contact, while an arc-shortening copper rod enhances short-circuit interruption performance for distribution system stability.
Loadbreak-type units feature an arc chamber made of special reinforced nylon, with high mechanical strength, anti-aging, and flame retardant properties. All products are manufactured and tested in strict accordance with IEC 60282-2:2008, IEEE Std C37.41-2008, and IEEE Std C37.42-2009 standards, ensuring consistent performance in standardized distribution projects.
Primary side protection of 11kV distribution transformers in urban and rural distribution networks
Short-circuit protection for branch lines of medium-voltage electrical distribution systems
Overcurrent and short-circuit protection for capacitor banks in distribution infrastructure
Power distribution systems for industrial plants, municipal public facilities, and commercial complexes
Sectionalizing and switching operations for conventional distribution networks
We offer flexible customization for our 11kV standard fuse cutout to match your distribution project requirements, including rated voltage/current adjustment, minimum creepage distance customization, porcelain/polymer insulator material selection, arc-shortening rod configuration, and mounting bracket type matching. We support bulk batch supply for large-scale distribution projects, with strict production scheduling to ensure on-time delivery, and full pre-delivery testing for every batch to guarantee consistent quality.
HAIVOL is a professional manufacturer of high voltage fuse cutouts with decades of experience in electrical distribution protection solutions. Our 11kV high voltage electrical distribution fuse cutout is produced in a standardized production workshop with full-process quality control, and each product undergoes strict type testing before delivery. We provide comprehensive pre-sales technical support and after-sales service, with a professional technical team to offer on-site installation guidance and troubleshooting, helping you reduce project costs and improve distribution system reliability.
All our fuse cutouts are manufactured and tested in full accordance with the latest international standards IEC 60282-2:2008, IEEE Std C37.41-2008, and IEEE Std C37.42-2009.
Yes, we support customized minimum creepage distance from 220mm to 900mm to adapt to coastal, high-altitude, and other special environmental requirements.
The standard rated current is 100A and 200A, which can meet the protection requirements of most conventional 11kV distribution systems.
