A transmission line arrester keeps power lines safe from high voltage surges. It takes in energy from lightning and switching events. This stops dangerous overvoltages from reaching insulators. This helps prevent flashover, which can cause outages and damage equipment. Studies show that using transmission line arresters makes the system more reliable. It lowers the number of insulation failures. There are different types, like EGLA and MOSA. Each type has special benefits for reliability and maintenance.
Reliability gets better when engineers choose the right number and spots for arresters. This makes lightning protection work well.
The arrester helps keep networks safe and steady.
Transmission line arresters keep power lines safe. They move high voltage surges to the ground. These surges come from lightning or switching events.
Arresters stop insulator flashover. This helps prevent power outages and stops equipment from breaking. It makes the power system work better.
There are different types of arresters. MOV and externally gapped arresters are two examples. Each type has its own good points. They help with cost, care, and lightning safety.
Arresters must be put in the right place. They need to be installed well on power lines and towers. This helps them work best and lowers outages.
Checking and fixing arresters often is important. This keeps them working right. It helps power systems stay safe and saves money on repairs.
A transmission line arrester is a device that protects power lines from high voltage surges. IEEE standards say it helps stop insulator flashover during lightning and switching events. It keeps insulators safe by lowering voltage and sending surge currents to the ground. IEC standards put line arresters into two groups: non-gapped line arresters (NGLAs) and externally gapped line arresters (EGLAs). These groups focus on how much energy and charge the arresters can handle.
Arresters do not change normal power voltages. They only work when there is too much voltage, like during lightning or switching surges. Arresters are made to survive short times of high voltage and keep insulators safe.
Tip: Engineers pick arresters based on system voltage, weather, and how reliable they need to be.
Transmission line arresters help keep power systems safe and working well. They stop insulator flashover, which can cause power outages and damage. Flashover happens when voltage gets too high and electricity jumps across the insulator. This can cause faults and make breakers turn off.
Some main causes of insulator flashover are pollution, lightning, bird damage, corona effects, and stress from the environment. The table below lists these causes and explains them:
Cause | Description |
|---|---|
Pollution | Dirty stuff builds up on insulators, making them weaker, especially when it is humid. |
Lightning Strikes | Happens a lot in open or hilly places and can break insulators. |
Bird Damage | Birds can cause flashover, especially on high voltage lines; composite insulators are more at risk. |
Corona Effects | Strong electric fields near fittings can cause corona discharge and hurt insulator safety. |
Environmental Stress | Ice, snow, very hot or cold weather, and high places put stress on insulators and can cause flashover. |
Arresters help by moving surge currents away from insulators. They keep voltage at safe levels and lower the chance of flashover. Here are some important things arresters do:
Stop insulator back flashover by sending lightning current from the ground to the phase conductor.
Help breakers last longer by making them work less often.
Lower system losses by using arresters instead of overhead ground wires.
Save money on building costs compared to using ground wires.
Make the system more reliable and almost safe from lightning.
Allow for smaller right-of-way areas by controlling switching surges.
Help with tower ground resistance so lightning protection works better.
Cut down on short power outages from lightning by protecting parts or all of the line.
Transmission line arresters are put next to insulators. They share lightning current between towers and phases, making the system stronger. If arresters are on every phase of every tower, the line is almost safe from lightning outages.
Note: New arresters use metal oxide varistors (MOVs) for better protection and reliability.
Transmission line arresters help protect power lines from surges. They notice when voltage gets too high. Then, they change from blocking electricity to letting it pass. This lets the extra current move safely to the ground. Arresters keep equipment safe from high voltages caused by lightning or switching.
These arresters handle voltages from their normal level, like 330 kV, up to very high surges. For example, 420 kV equipment can get hit by surges as high as 1425 kV. Experts say surge voltages should stay below 1239 kV to keep insulation safe. Arresters stop these surges and keep the system working.
The table below shows how each arrester type sends surge currents to the ground:
Mechanism Type | Description | How Surge Current is Diverted to Ground |
|---|---|---|
Non-linear Resistor Type | Uses metal oxide varistors (MOVs) or silicon carbide. | Resistance drops sharply during surges, creating a low-impedance path to ground. |
Spark Gap Type | Air gaps between electrodes. | Air ionizes during surges, gap becomes conductive, current flows to ground. |
Rod Gap Arrester | Metal rods separated by air gap. | Air gap breaks down under surge voltage, current flows to ground. |
Horn Gap Arrester | Horn-shaped conductors. | Enhanced discharge capacity for higher surges. |
Multi-Gap Arrester | Multiple gaps in series or parallel. | Handles repetitive surges, provides multiple discharge points. |
Expulsion Type Arrester | Spark gaps and expulsion materials. | Surge ionizes material, path to ground forms. |
Hybrid Arrester | MOV block and expulsion gap combined. | Fast response and arc-quenching for robust protection. |
After the surge, arresters go back to blocking electricity. Good grounding and setup help them work better. They stop voltage spikes and keep insulators from failing. High flashover voltage and good spacing lower the chance of lightning problems. The number of arresters needed depends on how often lightning hits the ground nearby. This makes arresters very important for lightning safety.
Tip: Engineers put arresters on towers where lightning strikes often or where the soil is not good for grounding.
Arresters stop back flashover by moving surge currents away from insulators. Back flashover happens when lightning makes voltage rise at the bottom of insulators. This can make electricity jump from the tower to the wire and cause outages.
Putting arresters every 4 or 5 spans on power lines lowers flashover from indirect lightning and back flashover. This makes the system more reliable. But arresters do not help much with flashover from direct lightning, which is stronger.
The table below explains how arresters help stop flashover:
Aspect | Summary |
|---|---|
Effectiveness | Arresters reduce line outages by up to 68% in some case studies. |
Placement | Installed in parallel with insulators, especially on towers with high ground flash density. |
Types | Non-Gapped Line Arresters, Externally Gapped Line Arresters, Multi Chamber Insulator Arresters. |
Mechanism | Arresters divert surge currents, reducing energy stress on insulators. |
Limitations | Mainly reduce flashover from indirect strikes and back flashover. |
Practical Use | Arresters improve reliability and offer a cost-effective solution. |
Many things affect how well arresters stop flashover:
The way arresters are set up and how many are used matters. Putting arresters on all wires stops sudden high voltages and back flashover at the hit tower.
How well the tower is grounded and how strong the lightning is also matter.
Soil type and how often lightning hits decide if more arresters are needed.
How much energy arresters can take and how far apart they are is important.
Protecting nearby towers helps stop voltage from moving and causing back flashover.
Putting arresters close to substations lowers the risk of back flashover.
Tests and real-life data show that lines with arresters work better during storms. Studies on 150 kV lines show fewer failures when arresters are used, especially where the ground is not good and lightning is common.
Note: Arresters work best when installed and set up the right way. Engineers must check tower grounding, soil, and lightning for the best results.
Arresters are a smart and cheap way to make power lines more reliable. They lower flashover and help keep the power on.
MOV arresters help protect transmission lines from surges. They have a metal oxide varistor disk inside. This disk is made of zinc oxide and other metals. The disk sits between two electrodes in a strong case. Terminals connect the arrester to the power system.
Main components of MOV arresters:
Metal oxide varistor disk
Electrodes
Encapsulation
Terminals
MOV arresters block most current during normal times. Only a tiny current can pass through. When voltage gets close to the breakdown point, the varistor turns on. Its resistance drops very fast. Surge current goes through the arrester and down to the ground. The arrester stops extra voltage and keeps equipment safe. After the surge, it blocks current again.
How MOV arresters function:
High impedance during normal operation
Activation at breakdown voltage
Sharp drop in resistance
Voltage clamping to protect components
Recovery to high impedance
Inside the arrester, zinc oxide grains make up the varistor. At normal voltage, it lets almost no current flow. When a surge comes, resistance drops. Extra current moves to the ground quickly. This keeps equipment safe and the system working well.
Externally gapped arresters are also called EGLAs. They use a spark gap outside the main part. The gap is between the line and the arrester. It does not conduct during normal times. When a surge happens, the gap becomes active. Current jumps across the gap and goes to the ground.
Key features of externally gapped arresters:
Spark gap for surge activation
Fewer MOV blocks than traditional arresters
Lightweight and simple design
Minimal maintenance needs
The table below compares MOV arresters and externally gapped arresters:
Performance Aspect | MOV Arresters (NGLAs) | Externally Gapped Arresters (EGLAs) |
|---|---|---|
Residual Voltage | Higher residual voltage | Lower residual voltage due to external spark gap |
Electrical Stress | Higher electrical stress on varistor units | Less electrical stress, better aging performance |
Material & Cost | Require more MOVs, additional hardware | Require fewer MOVs, reduced material and cost |
Installation & Maintenance | Complex installation, heavier, mechanical stresses | Simple installation, lighter, minimal maintenance |
Switching Surge Control | Better for switching surge control | Less suitable for switching surge control |
Reliability | Potentially less reliable due to mechanical stresses | More reliable, resistant to mechanical stresses |
Application Suitability | Good for switching surge control | Superior for lightning performance and line uprating |
Externally gapped arresters give strong lightning protection. They help lower costs and are easy to install. Their design stands up to stress and lasts longer. Many engineers pick EGLAs for lines that need good lightning safety and reliability.
Tip: Pick the right arrester type based on what the system needs, cost, and how reliable it should be.
How engineers install transmission line arresters depends on voltage and line design. They use tables to pick the best way for each situation. The table below shows what to do in different cases:
Voltage Level / Scenario | Recommended Placement Methods for Transmission Line Arresters | Additional Notes |
|---|---|---|
69 kV (uprated to 138 kV) | Put arresters at line entrances and on every phase of towers, especially for compact lines | Keeps clearances safe without rebuilding substations; allows compact bus spacing |
138 kV (uprated from 69 kV) | Same as above: arresters at line entrances and on all tower phases | Helps raise voltage; less need to rebuild substations |
Substations | Use line entrance arresters to protect open breakers | Ground resistance should match substation ground resistance |
Compact Lines (e.g., 69 kV) | Put arresters on every phase of all towers | Makes the system more reliable and stops lightning outages |
Arresters work best when placed close to ground points. If lightning hits, the arrester near the ground sends surge current away fast. This keeps voltage low and stops insulation from failing. Good grounding and close placement help the system recover quickly after a surge.
Engineers use some important steps when installing surge arresters. These steps help stop double circuit outages and make the system stronger:
Put arresters on all phases of every pole, especially for double circuit lines.
Pick the number and spot for arresters based on line shape, shield wires, tower footing resistance, and land features.
On double circuit lines, arresters on one circuit can lower outages and stop them on the other.
Do not put arresters only every fourth or fifth pole, because this causes more outages from direct lightning.
Use special computer programs to plan and place arresters.
Think about ground resistance and shield wires when planning.
For underground parts, put arresters at riser poles and open points to stop voltage doubling.
Some mistakes can make arresters work less well. These include:
Lead wires that are too long, which can swing and get caught.
Leads or arresters touching insulation or parts of the structure.
Not enough space between the arrester and phase conductor.
Bad placement that stops the arrester from falling clear if it disconnects.
Trying to make things fit without thinking about how they work or fail.
Tip: Following these steps helps keep surge arrester installation safe and reliable. Careful planning and checking details stop outages and protect equipment.
Transmission line arresters help power systems work better. They protect lines from surges. They keep the lights on during storms. When lightning hits, arresters act quickly. They stop high voltages from reaching insulators. This prevents flashover. The system keeps running smoothly.
Data from Japan shows big improvements. After many arresters were installed, outage rates dropped by half. There were about 2.1 outages per 100 km each year. This matches Class "C" reliability. Double-circuit lines got even better. They reached Class "A" reliability since 2011. These results show arresters lower lightning outages. Power interruptions are shorter and happen less often.
Arresters also help by lowering breaker trips. Fewer trips mean less wear on equipment. Equipment lasts longer. Maintenance teams fix fewer problems. The whole system works better.
Tip: Putting arresters in good spots and picking the right type helps the system work best.
Arresters help save money on new transmission projects. Engineers can design towers that use less space. They need fewer materials. This saves money on land, building, and fixing things.
The table below shows how arresters change project costs:
Aspect | Without Arresters | With Arresters |
|---|---|---|
Switching Surge Factor (p.u.) | 3.5 or 3.0 | 2.5 |
Right-of-Way Width (m) | 86–92 | 80 |
Extra Land Needed (acres) | Up to 631 | Minimal |
Number of Towers | +38 | No increase |
Tower Design | Larger spacing | More compact |
Material & Construction Costs | Higher | Lower |
Live-line Maintenance | Harder | Easier |
Arresters let engineers raise voltage on old lines. They do not need to rebuild. They also allow for smaller right-of-way widths. Less land is needed. Costs stay low. Towers can be compact. This saves money and space.
Note: Arresters give both reliability and cost savings. They are a smart choice for modern power systems.
Transmission line arresters can have problems that affect how well they work. Things like weather and how they are built can cause issues. The table below shows some common problems and what they do:
Reliability Concern | Description | Impact on Transmission Line Arresters |
|---|---|---|
Flexible leads and terminals wear out fast | Leads can break or come loose in the wind | Less space for electricity, higher chance of failure |
Bad installation of vibration dampers | Dampers do not protect against shaking | More stress on parts, wires can get damaged |
Aeolian vibration | Small, fast shakes happen many times | Parts get tired and break after a while |
Galloping motion | Big swings, often when ice is on wires | Can shake too much and break things, but not seen yet |
Installation mistakes found by EPRI | Not enough space, wrong setup, broken leads | Parts break easier, more electric noise, short circuits can happen |
No rules for mechanical reliability | No set rules for how strong arresters should be | Need more tests and surveys to make better rules |
CIGRE Task Force advice | Put dampers in the right place, use clamps right, let parts move freely | Arresters last longer and work better |
Water getting inside is a big reason arresters fail. It can cause sparks inside, wear down parts, and make short circuits. Both porcelain and polymer arresters can have this problem. Polymer types may have trouble if silicone does not stick well or water builds up. Too much electricity or short high voltages can make them overheat and break.
Weather like dirt and wet air also matters a lot. Composite housings with water-repelling surfaces keep out water and dirt better than porcelain. Tests put arresters in salty fog, wet air, and sunlight to see if they last. Special designs help in places with lots of dirt or wetness.
Checking arresters often helps them stay safe and work well. Workers look for things like:
Cracks, dents, or broken insulators
Burn marks or color changes
Worn out covers or cases
Parts that are melted or bent
Some arresters have a window that turns red when they are worn out. This shows it is time to change them right away. Workers also look for damage or burn marks.
Regular care means:
Looking for damage or wear
Testing if insulation still works and checking for leaks
Making sure all parts are tight and connected right
Watching for signs that show the arrester has failed
Composite arresters need less care than porcelain ones. Their surfaces clean themselves and keep off dirt better. Workers pick arresters based on how dirty or wet the area is. Good setup and regular checks help stop sudden failures and keep the power on.
Transmission line arresters are very important in today’s power systems. They keep equipment safe from surges and help stop outages. This helps the grid stay reliable. Studies show arresters take in surge energy and stop flashovers. They work even on high-voltage lines. New arresters are smarter and last longer. They are also easier to take care of.
They use better materials for stronger protection
They can be checked in real time with IoT
They are made to be good for the environment
Engineers can make systems work better by using best practices. They should also try new surge protection technologies.
A transmission line arrester keeps power lines safe from surges. It moves extra energy down to the ground. This helps the power stay on during storms.
Workers need to check arresters at least once every year. They look for cracks, burns, or loose pieces. Checking often helps stop problems before they start.
Arresters help stop damage from most lightning strikes. They work best for indirect strikes and back flashover. Direct lightning can still cause trouble sometimes.
Type | Main Feature |
|---|---|
MOV Arrester | Has a metal oxide varistor |
Externally Gapped | Uses a spark gap outside unit |
Each type has its own good points for cost and reliability.
Engineers use EGLA for strong lightning safety. It costs less and needs little care. It works well where lightning happens a lot.
