Pollution flashover occurs when conductive contaminants—salt, dust, industrial emissions—accumulate on insulator surfaces and combine with moisture to form a continuous conductive film. This film reduces insulation strength and can trigger flashover, leading to line trips and equipment damage.
Traditional countermeasures include periodic washing, silicone greasing, and adding insulator discs. However, washing is labor-intensive, and greasing requires frequent reapplication. Modern practice favors RTV silicone coatings and creepage distance optimization as more durable and economical solutions.
RTV silicone rubber coating is based on polydimethylsiloxane (PDMS). When applied to porcelain or glass insulators, it forms a thin, elastic hydrophobic film. This film prevents water from forming a continuous conductive layer on the surface.
A unique property of silicone is its ability to transfer hydrophobicity to the pollution layer itself. Low molecular weight silanes diffuse from the coating into the contaminants, making them water-repellent. This means even heavily polluted surfaces can maintain high flashover voltage.
· Hydrophobicity: Water contact angle typically exceeds 100°, causing droplets to bead and roll off.
· Hydrophobic transfer: Maintains performance even when the coating is covered by pollution.
· Anti-tracking and anti-erosion: Withstands electrical arcs without forming conductive carbon paths.
· Long service life: Effective for many years, reducing maintenance frequency.
· Wide temperature range: Suitable for -50°C to 100°C.
RTV can be applied by field spraying or factory dip coating. Factory dip coating is increasingly preferred for new insulators because it provides uniform thickness, better quality control, and reduced environmental impact. Field spraying is used for existing lines. Coating thickness should be at least 0.3 mm, applied uniformly without defects.
Creepage distance is the shortest path along the insulator surface between the energized conductor and the grounded end. A longer creepage distance increases the path length for leakage current, improving pollution flashover voltage. However, simply adding ribs or increasing length can create narrow spaces that trap pollution and promote arc bridging.
Research shows that arc paths on polluted insulators fall into two categories: cling-surface arcs and air-jump arcs. The probability of each depends on shed profile parameters—shed extension, spacing, and rib length. Optimal designs use alternating shed profiles with a rib spacing-to-length ratio between 0.67 and 1.5. This configuration maximizes creepage distance utilization and reduces flashover risk.
The required creepage distance depends on site pollution severity. IEC 60815 provides guidelines for determining the unified specific creepage distance (USCD). For heavily polluted areas, values of 40–50 mm/kV or higher may be required. In extreme coastal or desert conditions, some utilities specify up to 65 mm/kV.
The two approaches complement each other. RTV coating enhances the insulator's surface properties, providing immediate hydrophobic protection. Optimized creepage distance ensures that even if the coating ages or is damaged, the insulator retains sufficient electrical strength.
This synergy allows utilities to either:
· Use standard creepage distances with RTV coating to achieve performance comparable to longer insulators, or
· Use RTV coating in addition to increased creepage distance for extremely harsh environments.
Field experience supports this combined approach. In Kuwait, RTV-coated porcelain long rods have been successfully used in severe desert and marine pollution. In South Africa, RTV-coated insulators showed leakage currents only 27% of uncoated equivalents. Australian utilities have also adopted RTV coatings for coastal lines.
1. Assess pollution severity using IEC 60815 to determine required creepage distance.
2. Select optimized shed profiles with alternating ribs and proper spacing ratios.
3. Apply RTV coating by factory dip coating for new insulators or field spraying for existing ones.
4. Verify coating thickness (≥0.3 mm) and uniformity.
5. Monitor performance periodically, checking hydrophobicity and visual condition.
6. Maintain records to schedule recoating or replacement when needed.
Pollution flashover can be effectively mitigated through a comprehensive strategy combining RTV silicone coatings and optimized creepage distance design. RTV provides superior hydrophobicity and hydrophobic transfer, while creepage distance optimization ensures robust electrical performance. Together, they offer a reliable, cost-effective solution for transmission lines in polluted environments. Utilities adopting this dual approach can expect fewer outages, extended maintenance intervals, and improved system reliability.
