As power grid construction extends into complex environments, field installation efficiency and long-term reliability of cable accessories face critical challenges.
This study addresses two key pain points: modular rapid-installation processes and multi-level biological protection, significantly enhancing construction quality and service life.
Modular Pre-assembled Structure: Integrated stress cone/semiconductor layer reduces field assembly steps by 80%.
Smart Alignment System: Laser-guided slots and color codes ensure cable cutting accuracy (≤0.5mm error).
| Step | Operation | Time Savings (Conventional→Innovative) |
| Cable Prep | Integrated stripping/cleaning | 30min → 8min |
| Positioning | Auto-centering guide ring | 15min → 2min |
| Insulation | Self-expanding cold-shrink tube | 20min → Instant |
| Sealing | Nano-viscoelastic injection (3bar waterproof) | 24h → 1h |
1.3 Key Benefits
70% time reduction (e.g., 110kV joint installation: 4h → 75min)
Torque-limiting wrench (25N·m preset) prevents mechanical damage
2. Integrated Anti-Termite/Bioerosion Protection
2.1 Bioerosion Mecanism
- Termites: Formic acid dissolution of silicone rubber
- Microorganisms: Enzyme degradation of polymer chains
2.2 Triple-Layer Protection
| Level | Technology | Mechanism |
| Material | 0.5% Boron Nitride (BN) nanoparticles | Disables digestive enzymes |
| Structural | Corrugated stainless armor (gap≤0.3mm) | Physical barrier |
| Chemical | Slow-release microcapsules (≥15 years) | Pyrethroid compound emission |
After 3000h under tropical conditions (40°C/95%RH):
- Protected samples: Zero biological adhesion, tensile strength retention >92%
- Control group: Significant mildew & pitting (depth 1.2mm)
3. Field Application
312 sets deployed in Hainan rainforest transmission project (2024):
- Efficiency: Daily installation rate increased by 240%
- Reliability: Zero bioerosion failure in 18 months (vs. 6.7% conventional failure rate)
Conclusion
This integrated approach resolves field efficiency and long-term protection challenges. Future work will develop AI-assisted installation systems to advance smart grid construction.
